1、皮带过紧:会造成经常性的损坏皮带和后端轴承过热，造成轴承损坏也是振动的主要原因。如果转子振动也会产生共振现象发生。

1. Belt too tight: will cause frequent damage, belt and rear end bearing overheating, causing bearing damage is also the main cause of vibration. If the rotor vibrates, resonance will occur.

2、皮带过松:摩擦力会减小，皮带打滑，产生丢转现象，没有传送足够的功率，风机没有达到应有的效果。正确的安装方法应该是用手指按压其中一根皮带的中间部位，按压深度是一个皮带的厚度至两个皮带厚度之间为宜。

2. Too loose belt: the friction will decrease, the belt will slip, resulting in loss of rotation, insufficient power transmission, and the fan does not achieve the desired effect. The correct installation method should be to press the middle part of one belt with fingers, and the pressing depth should be between the thickness of one belt and the thickness of two belts.

公式:δ=0.016L(L:皮带轮中心距mm)要求A、B、C、D各点与线相接触且相互平行。

Formula: δ= 0.016l (L: pulley center distance, mm) requires a, B, C and D points to be in contact with the line and parallel to each other.

3、三角皮带应选用同一规格(批次)产品，同一规格如遇有长短不一现象时，应选取同等长度的使用，严禁装配上有其中一根或几根皮带过松，使其他皮带受力过载，皮带磨损快，禁止新旧混用。

3. V-belts shall be of the same specification (batch). In case of length difference, V-belts of the same specification shall be of the same length. It is strictly forbidden to loose one or more of the V-belts on the assembly, so that other belts are overloaded and worn quickly. It is forbidden to mix the old with the new.

无论选用哪种三角皮带，都要先看清皮带轮的型号和条数再安装。

No matter what kind of V-belt is selected, the model and number of pulleys should be seen before installation.

感谢您的阅读，希望对您有所帮助！

Thank you for reading, hope to help you!
