回转风机在使用过程中,经常会遇到发热的情况,发热的原因有哪些?什么因素会造成回转风机的温度升高?采取什么措施可以改善回转风机发热的状况呢?下面甘肃回转风机厂家为大家介绍一下。
Rotary fan in the process of use, often encounter heating, what are the causes of heating? What causes the temperature rise of the rotary fan? What measures can be taken to improve the heating condition of rotary fan? Next Gansu rotary fan manufacturers for you to introduce.
1、回转风机在正常使用的情况下会有一定的升温,尤其是受季节因素的影响,条件允许的情况下尽量是采用两台机器交替运行,夏季8小时切换一次,冬季12小时切换一次;当采用一台风机运行时,夏季每工作8小时停机一次,冬天可以12小时停机一次。
1. The rotary fan will have a certain temperature rise under normal use, especially due to the influence of seasonal factors. If conditions permit, the two machines should be operated alternately, once every 8 hours in summer and once every 12 hours in winter; When one fan is used, it can be shut down every 8 hours in summer and 12 hours in winter.
2、回转风机进风口进风不畅,原因是进口滤清器堵塞,根据回转风机的使用环境,请半月到一个月清洗一次空气滤清器,当使用时间过久,需要对空气过滤器进行更换。
2. The air inlet of the rotary fan is not smooth because the inlet filter is blocked. According to the service environment of the rotary fan, please clean the air filter once a half month to a month. If the service time is too long, the air filter needs to be replaced.
3、风机房太小或者风机房通风设计有缺陷,造成通风不畅影响风机的进气,建议风机房留有足够的空间,并保持清洁,通风良好。
3. The fan room is too small or the ventilation design of the fan room is defective, resulting in poor ventilation and affecting the air intake of the fan. It is suggested that the fan room should be kept clean and well ventilated with enough space.
4、回转风机内部损伤,有可能有异物、脏污进入内部,建议拆机检查风机,排除异物或者赃物。
4. The internal damage of the rotary fan may cause foreign matters and dirt to enter into the fan. It is recommended to dismantle the fan and check the fan to remove foreign matters or stolen goods.
5、回转风机缺乏润滑油,首先考虑是不是回转风机空载运行,回转风机利用工作室产生的压力差而行成自动供油,如果没有压力差,则回转风机不能正常润滑。其次检查油箱的储油量是否低于刻度线,如机油不足,请及时添加润滑油。
5. The rotary fan is lack of lubricating oil. The first consideration is whether the rotary fan is in no-load operation. The rotary fan uses the pressure difference generated by the working room to supply oil automatically. If there is no pressure difference, the rotary fan cannot be lubricated normally. Secondly, check whether the oil storage capacity of the oil tank is lower than the scale line. If the oil is insufficient, please add lubricating oil in time.
6、回转风机润滑度不够,请检查润滑油调节系统,考虑在调节滴油速度的时候,调节阀旋钮没有调节好。需要按照风机型号的大小调整滴油速度,不同型号的回转风机有不同的滴油数量要求。
6. The lubricating degree of the rotary fan is not enough. Please check the lubricating oil control system. Consider that the control valve knob is not adjusted properly when adjusting the oil dropping speed. It is necessary to adjust the oil dripping speed according to the size of the fan model. Different types of rotary fans have different requirements for the amount of oil dripping.
7、回转风机的润滑油品质低,或者运行一段时间后油质变差,或者润滑油中混入水分造成变质。请检查回转风机润滑油系统,检查润滑油质量是否符合标准。回转风机一般采用68#耐磨液压油;寒冷地区可以适当降低标号,使用42#耐磨液压油;较大机型夏季尽量使用100#抗磨液压油。如发现润滑油有问题,请更换指定润滑油。
7. The lubricating oil quality of rotary fan is low, or the oil quality becomes worse after running for a period of time, or the lubricating oil is mixed with water to cause deterioration. Please check the lubricating oil system of rotary fan and check whether the quality of lubricating oil meets the standard. The rotary fan generally adopts 68 × wear-resistant hydraulic oil; In cold areas, the grade can be reduced appropriately and 42 ᦇ wear resistant hydraulic oil can be used; For larger models, 100 ᦇ anti-wear hydraulic oil shall be used as far as possible in summer. If any problem is found in the lubricating oil, please replace the specified lubricating oil.
8、回转风机安全阀(泄压阀)失灵,造成风机运转压力过高,请调整或更换安全阀,保证安全阀(泄压阀)可以正常的启闭。
8. The safety valve (pressure relief valve) of the rotary fan is out of order, resulting in high operating pressure of the fan. Please adjust or replace the safety valve to ensure that the safety valve (pressure relief valve) can be opened and closed normally.
9、压力过高会造成超负荷,回转风机升压为49kpa,请观察压力表指示数值,并检查管路是否有堵塞。
9. If the pressure is too high, it will cause overload. The pressure rise of the rotary fan is 49kpa. Please observe the indication value of the pressure gauge and check whether the pipeline is blocked.
感谢您的阅读,希望以上内容能对您有所帮助,如您想了解更多精彩内容请点击我们的官网:甘肃回转风机厂家http://www.sdyqtc.com。
Thank you for reading, hope the above content can help you, if you want to know more wonderful content, please click our official website: Gansu rotary fan manufacturer http://www.sdyqtc.com .
...
